Integrated Air Quality Sensor
AIS-8100AIS-8100

AIS-8100 sensor is an integrated air quality sensor for vehicle air quality monitoring. By integrated PM sensing based on laser scattering technology and CO2 sensing based on advanced NDIR technology, AIS-8100 sensor can output accurate and fast PM2.5 and CO2 concentration measurement via CAN communication. It helps to give a real time vehicle in-cabin air quality monitoring, and provides a health and comfortable in-cabin environment for both drivers and passengers.

Product Inquiry

Features

PM2.5 and CO2 simutaneous output
Laser scattering technology adopted, the smallest size of available measurement: 0.3μm
Real-time PM2.5 output in μg/m3
NDIR technology adopted for high accuracy CO2 concentration measurement
Beneficial from built-in fan, CO2 level measurement is in faster response
Auto-calibration for CO2 sensing
High-temperature laser module , resistant up to 85℃
Long lifetime laser
Vehicle-level (AEC-Q compliance) circuit design can be suitable to the harsh vehicle environment
CAN real-time communication

Specifications

	CO2 Sensor CM1106-C
Operating principle	PM: Laser light scattering;CO2: NDIR
Measured paride range	0.3μm ~ 2.5μm
Measurement range	PM2.5: 5~500μg/m³; CO2: 400-5000ppm
Resolution	PM2.5: 1μg/m³; CO2:1ppm
PM2.5 accuracy	±5μg/m³ or ±10% of reading
CO2 accuracy	±5% of reading
Data refresh time	≤1s
Digital output	CAN
IP rating	IP54
Noise	≤35dB(A)@50cm
Working condition	-40~+70C .5-95%RH (non-condensing)
Storage condition	-40~+85C ,5 -95%RH (non-condensing)
Power supply	DC 12V( DC 9V ~16 V compatible)
Working current	≤150mA
Standby current	≤100μA
