Li-battery Thermal Runaway Sensor

Product0

Get the Products

Product Recommendation Matrix

Product	CO2: NDIR (No-Dispersive Infrared)	PM2.5: LSD (Light Scattering)	CO/HC/NO2: MEMS (Microelectronic Mechanical Systems)	Temperature & Pressure	Target Measurement	Measurement Range
Automotive Li-battery Thermal Runaway Sensor ATRS-1020 ATRS-1020	●	●	●	●	CO, CO2, PM, Pressure, Temperature	CO:0ppm~1000ppm (Display up to 3Kppm) CO2:0ppm~10000ppm (Display up to 60Kppm) PM:0~5000ug/m³ P:80kPa~120kPa T:-40℃~120℃	Specifications Features PM2.5: LSD (Light Scattering) ● CO/HC/NO2: MEMS (Microelectronic Mechanical Systems) ● Temperature & Pressure ● Target Measurement CO, CO2, PM, Pressure, Temperature
Automotive Li-battery Thermal Runaway Sensor ATRS-1010 ATRS-1010	●		●	●	CO, CO2, Pressure, Temperature Customizable for CH4,H2	CO:0ppm~1000ppm (Display up to 3Kppm) CO2:0ppm~10000ppm (Display up to 60Kppm) P:80kPa~120kPa T:-40℃~120℃ Customizable for CH4,H2	Specifications Features PM2.5: LSD (Light Scattering) CO/HC/NO2: MEMS (Microelectronic Mechanical Systems) ● Temperature & Pressure ● Target Measurement CO, CO2, Pressure, Temperature Customizable for CH4,H2
Battery Safety Aerosol Sensor ATRS-1031 ATRS-1031		●			PM size >0.3μm	0~10000μg/m³	Specifications Features PM2.5: LSD (Light Scattering) ● CO/HC/NO2: MEMS (Microelectronic Mechanical Systems) Temperature & Pressure Target Measurement PM size >0.3μm
Automotive Li-battery Thermal Runaway Sensor APMS-3002 APMS-3002		●			PM size >0.3μm	0~10000μg/m³	Specifications Features PM2.5: LSD (Light Scattering) ● CO/HC/NO2: MEMS (Microelectronic Mechanical Systems) Temperature & Pressure Target Measurement PM size >0.3μm

Li-battery Thermal Runaway Sensor

Li-battery Thermal Runaway Detection Integrated Sensor ATRS-1012

ATRS-1012

Cubic ATRS-1012 sensor is a Li-battery thermal runaway detection sensor that can effectively monitor CO2 and H2 released from lithium-ion batteries, and generate an early warning signal to Battery Management System (BMS), to formulate safety alarm strategies.

Learn more

Specifications Features

Operating Principle

NDIR(Non-dispersive Infrared)
TC (Thermal Conductivity)

Detection Category 1

CO2 (NDIR Technology)

Detection Category 1

H2 (Thermal Conductivity Technology)

Measurement of CO2

Measuring Range: 0ppm~50,000ppm
Accuracy: ±(0.1%vol + 10% of reading)
- Automotive grade components
- Fast response time(<1s)
- Non-dispersive infrared (NDIR) CO2 sensor (fast response and high accuracy)
- Thermal conductivity H2 gas sensor (high reliability technology)
- Less cross interference with other gases
- Innovated combined sensing components for more reliable monitoring
Gas Leakage Detection MEMS Thermal Conductivity Hydrogen Sensor ATRS-1016-C

ATRS-1016-C

Cubic ATRS-1016 series is a MEMS Thermal Conductivity Hydrogen sensor that can effectively monitor H2 leakage and generate an early warning signal to formulate safety alarm strategies.

Learn more

Specifications Features

Operating Principle

TC (Thermal Conductivity)

Detection Category

H2

Measurement Range

0~10%vol( 0~4%vol accuracy guaranteed)

Accuracy

H2 vol.% in air ≤4%: ±0.4vol.%
H2 vol.% in air＞4%: ±10%
@-40℃-85℃, 0%-95%RH
- Automotive grade components
- Fast response time(<1s)
- Thermal conductivity H2 gas sensor (high reliability technology)
- Wide H2 detection range from 0 up to 10%
- Low power consumption
- Less cross interference with other gases
Automotive Li-battery Thermal Runaway Sensor ATRS-1010

ATRS-1010 sensors can effectively monitor CO2, CO/HC/H2 released before the thermal runaway trigger of lithium-ion batteries, as well as temperature and pressure, and transmit the measurement signal via CAN communication to new energy battery management system (BMS), to formulate safer early warning strategies.

Learn more

Specifications Features

Operating principle

NDIR(dual channel non-dispersive Infrared) technology
MEMS (Microelectronic Mechanical Systems)
Measurement target: CO2,CO/HC/H2,Temperature

Measurement range

CO:0ppm~1000ppm(Display up to 3Kppm)
CO2:0ppm~10000ppm(Display up to 60Kppm)
Temperature:-40℃~120℃

Resolution

CO2/CO/HC/H2：1ppm
Temperature：0.1℃

Accuracy

CO2:±（50ppm+5%reading）
CO：±40ppm or ±30% max reading
Temperature：±2℃
- Non-dispersive infrared (NDIR) technology adopted for fast response and high accuracy CO2 concentration measurement.
- Microelectronic Mechanical Systems adopted for fast response and high selectivity on CO/HC/H2 measurement.
- Integrated automotive sensor measures both CO2, CO/HC/H2, and temperature
- Key components are self-made to ensure quality and long life span
- Target measurement and range customizable
- CAN real time communication and vehicle-level circuit design
- Effectively and accurately measurement for combustible gas
- Comprehensive assessment for li-ion battery thermal runaway
- Reliable early warning for EV battery leakage
Automotive Li-battery Thermal Runaway Sensor ATRS-1020

ATRS-1020 sensors can effectively monitor CO2, CO/HC/H2 and particulate matters released before the thermal runaway trigger of lithium-ion batteries, as well as temperature and pressure, and transmit the measurement signal via CAN communication to battery management system (BMS), to formulate safer early warning strategies.

Learn more

Specifications Features

Operating principle

NDIR(dual channel non-dispersive Infrared) technology
MEMS (Microelectronic Mechanical Systems)
LSD(Laser scattering)

Measurement target

CO2,CO/HC/H2,PM2.5,Temperature

Measurement range

CO:0ppm~1000ppm(Display up to 3Kppm)
CO2:0ppm~10000ppm(Display up to 60Kppm)
PM2.5:0~5000ug/m³
Temperature: -40℃~120℃

Resolution

CO2/CO/HC/H2：1ppm
PM2.5：1ug/m³
Temperature：0.1℃
- Non-dispersive infrared (NDIR) technology adopted for fast response and high accuracy CO2 concentration measurement
- Laser scattering (LSD) technology adopted for high accuracy and large PM2.5 measurement range
- Microelectronic Mechanical Systems adopted for fast response and high selectivity on CO/HC/H2 measurement
- Integrated automotive sensor measures both CO2, CO/HC/H2, PM 2.5 and temperature
- Key components are self-made to ensure quality and long life span
- CAN real time communication and vehicle-level circuit design
- Target measurement and range customizable
- Effectively and accurately measurement for combustible gas
- Comprehensive assessment for li-ion battery thermal runaway
- Reliable early warning for EV battery leakage
Automotive Li-battery Thermal Runaway Sensor APMS-3002

APMS-3002

APMS-3002 is a laser particle sensor module for automobiles. It is suitable for the internal environment of automobiles. The sensor can accurately measure the concentration of particulate matter through mathematical algorithms and scientific calibration, and transmit the measurement signal to the master node through CAN communication.

Learn more

Specifications Features

Operating principle

LSD(Laser Scattering) technology

Measurement target

PM2.5 (particulate matters)

Measurement range

0~10000μg/m³

Measurement particle size

＞0.3μm
- Laser scattering (LSD) technology to achieve wide range measurement
- Reliable warning for li-ion battery thermal runaway
- Mature car-level circuit design no cross interference, stable perfomance
- High temperature laser module, constant power output
- CAN real-time communication
- Key components are self-made to ensure quality and long life span
- Low power consumption mode available
Battery Safety Aerosol Sensor ATRS-1031

ATRS-1031

ATRS-1031 aerosol sensor is an infrared (LED) particle sensor for automobiles. Effectively monitor the dust concentration released before the thermal runaway trigger of lithium-ion batteries

Learn more

Specifications Features

Operating Principle

PM (Particulate Matter): Infrared Scattering

Detection Category

PM (Particulate Matter)

Measurement Range

PM：0-10000ug/m³

Resolution

PM：1ug/m³
- Light scattering (LED) technology to report thermal runaway events in lithium-ion battery packs
- Aerosol threshold value of 5000 µg/m³ allows early detection of thermal runaway events
- Wake-up output and request input for high reliability system integration
- Mature vehicle level circuit design suitable for various automotive application
- Key components are self-made to ensure quality and long life span
- Low power consumption mode available
- CAN communication
