Residential Ultrasonic Gas Meter

Residential & Commercial Ultrasonic Gas Meter

Product0

Get the Products

Product Recommendation Matrix

Model Number	Technology	Key Specification	Measurement Range	Working Temperature & Pressure	Wireless Communication	Target Gas	T+P Compensaton
Residential Ultrasonic Gas Meter USM-RA-G1.6/G2.5/G4, USM-RS-G1.6/G2.5/G4 USM-RA-Series	Ultrasonic	Aluminium Case Center Distance: 110mm Thread: G1-1/4	USM-RA-G1.6: 0.016~2.5 m³/h USM-RA-G2.5: 0.025~4 m³/h USM-RA-G4: 0.04~6 m³/h	﹣25℃~55℃ 0~20Kpa	GPRS/NBIOT	Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG	Standard:Temperature Compensation Optional: Pressure Compensation	Specifications Features Key Specification Aluminium Case Center Distance: 110mm Thread: G1-1/4 Measurement Range USM-RA-G1.6: 0.016~2.5 m³/h USM-RA-G2.5: 0.025~4 m³/h USM-RA-G4: 0.04~6 m³/h Working Temperature & Pressure ﹣25℃~55℃ 0~20Kpa Wireless Communication GPRS/NBIOT Target Gas Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG T+P Compensaton Standard:Temperature Compensation Optional: Pressure Compensation
Residential Ultrasonic Gas Meter USM-RA-G1.6/G2.5/G4, USM-RS-G1.6/G2.5/G4 USM-RS-Series	Ultrasonic	Steel Case Center Distance: 130mm Thread: M30	USM-RS-G1.6: 0.016~2.5 m³/h USM-RS-G2.5: 0.025~4 m³/h USM-RS-G4: 0.04~6 m³/h	﹣25℃~55℃ 0~20Kpa	GPRS/NBIOT	Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG	Standard:Temperature Compensation Optional: Pressure Compensation	Specifications Features Key Specification Steel Case Center Distance: 130mm Thread: M30 Measurement Range USM-RS-G1.6: 0.016~2.5 m³/h USM-RS-G2.5: 0.025~4 m³/h USM-RS-G4: 0.04~6 m³/h Working Temperature & Pressure ﹣25℃~55℃ 0~20Kpa Wireless Communication GPRS/NBIOT Target Gas Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG T+P Compensaton Standard:Temperature Compensation Optional: Pressure Compensation
Commercial Ultrasonic Gas Meter USM-LCA- G6/G10/G16 USM-LCA-Series	Ultrasonic	Aluminium Case Center Distance: 150mm Thread: G1-1/2	USM-LCA-G6: 0.06~10 m³/h USM-LCA-G10: 0.1~16 m³/h USM-LCA-G16: 0.16~25 m³/h	﹣25℃~55℃ 0~50Kpa	GPRS/NBIOT	Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG	Standard: Temperature+Pressure Compensation	Specifications Features Key Specification Aluminium Case Center Distance: 150mm Thread: G1-1/2 Measurement Range USM-LCA-G6: 0.06~10 m³/h USM-LCA-G10: 0.1~16 m³/h USM-LCA-G16: 0.16~25 m³/h Working Temperature & Pressure ﹣25℃~55℃ 0~50Kpa Wireless Communication GPRS/NBIOT Target Gas Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG T+P Compensaton Standard: Temperature+Pressure Compensation
Commercial Ultrasonic Gas Meter USM-LCA- G6/G10/G16 USM-LCA-L-Series	Ultrasonic	Aluminium Case Center Distance: 150mm Thread: G1-1/2	USM-LCA-L-G6: 0.06~10 m³/h USM-LCA-L-G10: 0.1~16 m³/h USM-LCA-L-G16: 0.16~25 m³/h	﹣40℃~55℃ 0~50kPa	GPRS/NBIOT	Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG	Standard: Temperature+Pressure Compensation	Specifications Features Key Specification Aluminium Case Center Distance: 150mm Thread: G1-1/2 Measurement Range USM-LCA-L-G6: 0.06~10 m³/h USM-LCA-L-G10: 0.1~16 m³/h USM-LCA-L-G16: 0.16~25 m³/h Working Temperature & Pressure ﹣40℃~55℃ 0~50kPa Wireless Communication GPRS/NBIOT Target Gas Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG T+P Compensaton Standard: Temperature+Pressure Compensation
Commercial Ultrasonic Gas Meter USM-MCA-G25, USM-HCA-G40/G65 USM-MCA-Series	Ultrasonic	Aluminum Case Center Distance: 180mm Thread: G2	USM-MCA-G25: 0.25~40 m³/h	﹣25℃~55℃ 0~50kPa	GPRS/NBIOT	Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG	Standard: Temperature+Pressure Compensation	Specifications Features Key Specification Aluminum Case Center Distance: 180mm Thread: G2 Measurement Range USM-MCA-G25: 0.25~40 m³/h Working Temperature & Pressure ﹣25℃~55℃ 0~50kPa Wireless Communication GPRS/NBIOT Target Gas Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG T+P Compensaton Standard: Temperature+Pressure Compensation
Commercial Ultrasonic Gas Meter USM-MCA-G25, USM-HCA-G40/G65 USM-MCA-L-Series	Ultrasonic	Aluminum Case Center Distance: 180mm Thread: G2	USM-MCA-L-G25: 0.25~40 m³/h	﹣40℃~55℃ 0~50kPa	GPRS/NBIOT	Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG	Standard: Temperature+Pressure Compensation	Specifications Features Key Specification Aluminum Case Center Distance: 180mm Thread: G2 Measurement Range USM-MCA-L-G25: 0.25~40 m³/h Working Temperature & Pressure ﹣40℃~55℃ 0~50kPa Wireless Communication GPRS/NBIOT Target Gas Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG T+P Compensaton Standard: Temperature+Pressure Compensation
Commercial Ultrasonic Gas Meter USM-MCA-G25, USM-HCA-G40/G65 USM-HCA-Series	Ultrasonic	Aluminum Case Center Distance: 180mm Thread: G2-1/2	USM-HCA-G40: 0.4~65 m³/h USM-HCA-G65: 0.65~100 m³/h	﹣25℃~55℃ 0~50kPa (standard) 0~250kpa (optional)	GPRS/NBIOT	Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG	Standard: Temperature+Pressure Compensation	Specifications Features Key Specification Aluminum Case Center Distance: 180mm Thread: G2-1/2 Measurement Range USM-HCA-G40: 0.4~65 m³/h USM-HCA-G65: 0.65~100 m³/h Working Temperature & Pressure ﹣25℃~55℃ 0~50kPa (standard) 0~250kpa (optional) Wireless Communication GPRS/NBIOT Target Gas Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG T+P Compensaton Standard: Temperature+Pressure Compensation
Commercial Ultrasonic Gas Meter USM-MCA-G25, USM-HCA-G40/G65 USM-HCA-L-Series	Ultrasonic	Aluminum Case Center Distance: 180mm Thread: G2-1/2	USM-HCA-L-G40: 0.4~65 m³/h USM-HCA-L-G65: 0.65~100 m³/h	﹣40℃~55℃ 0~50kPa (standard） 0~250kpa (optional)	GPRS/NBIOT	Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG	Standard: Temperature+Pressure Compensation	Specifications Features Key Specification Aluminum Case Center Distance: 180mm Thread: G2-1/2 Measurement Range USM-HCA-L-G40: 0.4~65 m³/h USM-HCA-L-G65: 0.65~100 m³/h Working Temperature & Pressure ﹣40℃~55℃ 0~50kPa (standard） 0~250kpa (optional) Wireless Communication GPRS/NBIOT Target Gas Standard: Natural Gas, Natural Gas+23% Hydrogen Optional: LPG T+P Compensaton Standard: Temperature+Pressure Compensation

Residential & Commercial Ultrasonic Gas Meter

Commercial Ultrasonic Gas Meter
USM-LCA- G6/G10/G16

Gas Meter(USM-LCA- G6/G10/G16)

Commercial ultrasonic gas flow meters for sale – accuracy class 1.5 for commercial application, are with built-in valve, no mechanical moving parts, no magnetic induction elements.

Learn more

Specifications Features

Measurement Range

USM-LCA-G6: 0.06~10 m³/h [2.12~353.14ft³/h]
USM-LCA-G10: 0.1~16 m³/h [3.53~565.02 ft³/h]
USM-LCA-G16: 0.16~25 m³/h [5.65~882.85 ft³/h]

Accuracy

Class 1.5

Additional permissible error outside the temperature range from -25 ⁰С to +55 ⁰С
for every 10 ⁰С deviation from the range limit

USM-LCA-Series: -;
USM-LCA-L-Series: ±0.4%

Gas Medium

Natural Gas/ Natural Gas+23%H2/ LPG
- Innovative ultrasonic gas flow sensor technology;
- Built-in temperature and pressure compensation;
- High measurement sensitivity and accuracy with intelligent software algorithm for air,100% CH4, H1 and different natural gases;
- Long-term stability of accuracy;
- Anti-contamination, high corrosion resistance;
- Low pressure loss due to absence of obstructing objects within flow path;
- No magnetic induction elements, free from magnetic field effect;
- Low power consumption, long lifespan;
- Low operation & maintenance cost;
- Compact size, light weight, easy installation;
- Compliant to OIML R137 and EN14236 class 1.5;
- GPRS and NB-IoT solutions are optional.
Commercial Ultrasonic Gas Meter
USM-MCA-G25, USM-HCA-G40/G65

Gas Meter(USM-MCA-G25, USM-HCA-G40/G65)

Commercial smart ultrasonic natural gas meter gas flow meter, with wide turndown radio that allows accurate measurement for low flow, no calibration in use.

Learn more

Specifications Features

Measurement Range

USM-MCA-G25：0.25~40 m³/h [8.83~1412.6 ft³/h]
USM-HCA-G40：0.4~65 m³/h [14.13~2295.41 ft³/h]
USM-HCA-G65：0.65~100 m³/h [22.95~3531.4 ft³/h]

Accuracy

Class 1.5

Error ( -25℃~+55℃)

Qmin≤Q<0.1Qmax: ±3%;
0.1Qmax≤Q≤Qmax:±1.5%

Additional permissible error outside the temperature range from -25 ⁰С to +55 ⁰С
for every 10 ⁰С deviation from the range limit

USM-MCA/HCA-Series: -; USM-MCA/HCA-L-Series: ±0.4%
- Innovative ultrasonic gas flow sensor technology;
- Built-in temperature and pressure compensation;
- High measurement sensitivity and accuracy with intelligent software algorithm for air,100% CH4, H1 and different natural gases;
- Long-term stability of accuracy;
- Anti-contamination, high corrosion resistance;
- Low pressure loss due to absence of obstructing objects within flow path;
- No magnetic induction elements, free from magnetic field effect;
- Low power consumption, long lifespan;
- Low operation & maintenance cost;
- Compact size, light weight, easy installation;
- Compliant to OIML R137 and EN14236 class 1.5;
- GPRS and NB-IoT solutions are optional.
Residential Ultrasonic Gas Meter
USM-RA-G1.6/G2.5/G4, USM-RS-G1.6/G2.5/G4

Gas Meter(USM-RA-G1.6/G2.5/G4, USM-RS-G1.6/G2.5/G4)

Cubic specialize in designing and manufacturing of residential house prepaid natural gas meter with patented module, that are with high accuracy and wide turndown ratio.

Learn more

Specifications Features

Measurement Range

USM-RA/RS-G1.6: 0.016~2.5 m³/h [0.57 ~ 88.29 ft³/h]
USM-RA/RS-G2.5: 0.025~4 m³/h [0.88 ~ 141.26 ft³/h]
USM-RA/RS-G4: 0.04~6 m³/h [1.41 ~ 211.88 ft³/h];
USM-RA/RS-L-G1.6: 0.016~2.5 m³/h [0.57 ~ 88.29 ft³/h]
USM-RA/RS-L-G2.5: 0.025~4 m³/h [0.88 ~ 141.26 ft³/h]
USM-RA/RS-L-G4: 0.04~6 m³/h [1.41 ~ 211.88 ft³/h]

Accuracy

Class 1.5

Error

Qmin≤Q<0.1Qmax: ±3%;
0.1Qmax≤Q≤Qmax:±1.5%

Additional permissible error outside the temperature range from -25 ⁰С to +55 ⁰С
for every 10 ⁰С deviation from the range limit

USM-RA/RS-Series：-;
USM-RA/RS-L-Series: ±0.4%
- Stable flow field distribution;
- High sensitivity and accuracy with intelligent software algorithm for Air,100% CH4 and different natural gases;
- Low pressure loss due to absence of obstructing objects within flow path;
- Low power consumption;
- UART/TTL interface with direct output for connection;
- Small footprint which permit compact designs;
- Compliant to OIML R137 and EN14236 class 1.5.
