Refrigerant Gas Leakage Monitoring Sensor

Product0

Get the Products

Product Recommendation Matrix

Model Number

Technology
Gas

Dimension

Working Condition
(Ensure accuracy)

Measurement
Range

Output

Feature Spotlight

SJH-R32

SJH-R32

A2L Refrigerant Gas Sensor-R32

SJH-R32

NDIR
R32

￠20mm*19mm

-40~70℃

0~50%LFL

UART-TTL

Analog output

(0.4-2V)

Matrix calibration to ensure high accuracy over full temperature
Compact and reliable metal housing to fit for harsh environment

Specifications Features

Dimension: ￠20mm*19mm

Working Condition (Ensure accuracy): -40~70℃

Measurement Range: 0~50%LFL

Output: UART-TTL

Analog output

(0.4-2V)

AM4205

AM4205

A2L and A3 Refrigerant Gas Sensor-AM4205 Series

AM4205

NDIR
A2L ,A3
(R32,R290,R454A R454B,R454C)

76.8mm* 59.2mm* 19.5mm

-40 ~ 85℃

0~100%LFL

RS485+Modbus/

Analog output optional

Multiple refrigerate gas available among A2L & A3
Embedded temperature, humidity compensation
Linearization and factory calibration for accurate digital output
Matrix calibration to ensure high accuracy over full temperature
Fast response time T90≤30s
Automatic heating mechanism optional
UL,IEC compliance
Long lifespan over 15years

Specifications Features

Dimension: 76.8mm* 59.2mm* 19.5mm

Working Condition (Ensure accuracy): -40 ~ 85℃

Measurement Range: 0~100%LFL

Output: RS485+Modbus/

Analog output optional

Load More

Refrigerant Gas Leakage Monitoring Sensor

Portable Infrared Refrigerant Gas Leak Detector-AM4209

AM4209

Infrared Refrigerant Leak Detector, Gas Leakage Tester, A2L Gas detector, R32 R290 R410A R134a R454A R454B R1234yf Gas Detector, Portable Monitor, Freon Leak Detector, CFCs HCFCs HFCs Gas Leak Detector, Gas Detector with Rechargeable Battery, Refrigerant Leak Detection, Portable Refrigerant Monitor, Refrigerant leak detection and diagnosis

Learn more

Specifications Features

Measurement Gas

HFOs, blends and A2L gas

Maximum sensitivity

Static: 0.03oz/a (1g/a); motion: 0.1oz/a (3g/a)

Response time

＜1s (typical)

Working environment

0℃~40℃ (32℉~104℉), ＜75%RH (non-condensing)
- Non-dispersive infrared (NDIR) technology
- All HFOs and refrigerant blends available
- Ppm-level measurement sensitivity for faster leakage position
- Long life span of 10 years
- Built-in lithium battery with large capacity to support fast charging
- OEM & ODM design capability
NDIR High-temperature Resistive Refrigerant Leak Sensor-AM4203H

AM4203H

Cubic AM4203H is a refrigerant gas sensor based on NDIR technology, with best-in-class accuracy, fast response, superior resistance to high Temperature, humidity and pressure impact, specially designed for fan coil, gas furnace,heatpump applications.

Learn more

Specifications Features

Principle

Dual-beam NDIR

Measurement Range

0~100%LFL

Accuracy

2.5% LFL up to 25%LFL; ±5% LFL or 10% indication above 25%LFL

Response Time

T63≤30s
- Multiple A2L and A3 gases available( R32, R454A, R454B, R454C, R290, R1234ze, R1234yf)
- 0-100% LFL measurement range for refrigerant gases
- Excellent accuracy over full measurement range under matrix calibration
- High-temperature tolerant to 95℃
- Advanced auto baseline calibration mechanism, no field calibration required
- Integrated mitigation function
- Long lifespan of 15 years
- IEC 60335-2-40 & UL 60335-2-40 certified
- UL 60335-2-89 ed.2 Annex 101.DVP compliant
A2L Refrigerant Gas Sensor-R32

R32

Cubic refrigerant gas sensors and solutions mainly target the A2L mixtures,e.g. R32, R454A,R454B,R454C, R1234yf gas or that of a pure hydrocarbon in the blend like A3 R290.

Learn more

Specifications Features

Accuracy

0~3.6%vol. (0~25% LFL): ±0.54% vol. (3.75%LFL)
3.6%~7.2%vol (25% LFL~50%LFL) : ±15% of reading

Principle

NDIR

Measurement Range

0~7.2% vol (0~50%LFL)

Resolution

0.01% vol
- Dual Beam NDIR Technology
- Measurement range up to 0~100% LFL
- Matrix calibration to ensure high accuracy over full temperature -40~70℃
- Linearization and factory calibration for accurate digital output
- Standard industrial 4 series size ￠D20mm x H19mm, easily integrated.
- Metal body part, anti-corrosion, can work in tough working environment.
- Build-in/Embedded temperature and humility compensation
- Fast response
- Long lifetime
A2L and A3 Refrigerant Gas Sensor-AM4205 Series

AM4205

Cubic Refrigerant Gas Sensor is a OEM based product which could detect A2L refrigerant such as R454A,R454B ,R32.and R290 based on own patent NDIR technology.

Learn more

Specifications Features

Principle

NDIR

Measurement Gas

R32/R454A/R454B/R454C/R290

Measurement Range

0-100%LEL

Accuracy

±2.5% LFL
- Dual Beam NDIR Technology
- High Resolution
- Up to 0~100% LFL Range
- Digital output of gas concentration
- Factory calibrated
- Internal temperature sensor
- Built-in heater to avoid condensation and frost
- Fast response, long lifetime
- Faults Diagnostics & Error Generation
- OEM/ODM sensor detector is available
- IEC 60335-2-40 & UL 60335-2-40 certified
Industrial Infrared A2L and A3 Refrigerant Gas Sensor-AM4203 Series

AM4203 Series

Industrial Infrared A2L and A3 Refrigerant Gas Sensor-AM4203 Series is focused on NDIR refrigerant gas sensor that offers industrial grade accurate and reliable detection of A2L gases (including R32, R454A, R454B and R454C), and A3 gas R290.

Learn more

Specifications Features

Principle

Dual-beam NDIR

Measurement Range

0~50% LFL (Extendable up to 100% LFL)

Resolution

1%LFL

Accuracy

±2.5% LFL up to 25%LFL; ±5% LFL or 10% indication above 25%LFL
- Dual-beam NDIR technology
- 0-100% LFL measurement range for refrigerant gases
- Excellent accuracy over full meaurement range under matrix calibration
- Advanced auto baseline calibration mechanism
- Industrial grade 12/24VDC power supply, RS485 and Modbus communication
- Long life span of 15 years
- OEM and ODM flexible service
- IEC60335-2-40 & UL 60335-2-40 certified
NDIR A2L/A3 Refrigerant Gas Analyzer

Gasboard-3100 refrigerant gas analyzer series

Gasboard-3100 refrigerant gas analyzer series is a NDIR refrigerant gas analyzer, which leveraged Cubic gas analyzer platform and mature long gas chamber Non-dispersive infrared (NDIR) technology to fulfill superior accuracy and high stability of refrigerant gas measurement. It supports single or multiple refrigerant gases options available, including R32, R454A, R454B, R454C, R290, R1234yf and etc.

Learn more

Specifications Features

Supported Gas

A2L gases ( R32,R454A,R454B,R454C); A3 gas R290; CFC,HCFC,HFC,HFO,blends

Measure Range

0~100%LFL (customizable)

Accuracy

1%FS

Resolution

0.01%
- Long gas chamber NDIR technology
- Single or Multi channel optional
- Backlit LCD display provides intuitive and real-time readings
- Integrated RS232/RS485 digital output with 4-20mA analog output
- Offering option of Convenient calibration functions for zero point, full scale or customized multipoint manual calibration
- Built-in auto-zero pump, efficiently decrease the calibration frequency
- Modular sensor design, easy maintenance

Load More
