Oxygen concentrator plays a critical role in medical healthcare field by extracting oxygen from the air and provide patients with high concentration oxygen gas they need. To ensure these devices operate efficiently and reliably, the accurate measurement of air flow rate and oxygen concentration is essential. This not only impacts oxygen treatment effect but also affects the performance and safety of the equipment.
After the COVID-19 pandemic, many people are experiencing lingering respiratory issues that require regular inhalation of oxygen gas to keep healthy, which brings a booming up of oxygen concentrator market. Additionally, the increasing prevalence of asthma and Chronic Obstructive Pulmonary Disease (COPD) has further fueled this demand.
Approximately 317 million people globally suffer from COPD, with 26 million in the United States, 99 million in China, and 170 million in Europe. COPD is the third leading cause of death worldwide, causing 3.23 million deaths in 2019.
Around 339 million people worldwide have asthma, including 25 million in the United States, 30 million in Europe, and 30 million in China.
Both COPD and asthma are highlighted in the WHO's Global Action Plan for the Prevention and Control of Noncommunicable Diseases and the United Nations' 2030 Agenda for Sustainable Development.
Given these health challenges, oxygen concentrator is becoming increasingly essential. In 2023, the global oxygen concentrator market saw the sale of approximately 1.3 million units, and is expected to continue growing in the coming years.(via Grand View Research).
Based on advanced ultrasonic sensing technology, robust R&D capabilities, and testing & manufacturing advantages, Cubic could provide all-in-one solution for oxygen concentrator. This includes high-precision oxygen sensors for accurately measuring oxygen flow rate and concentration, low-noise cooling fans tailored for oxygen concentrators, as well as a main circuit board as the core of oxygen concentrator to ensure optimal performance of each units.
Cooling Fan
12038
PCB
Ultrasonic Oxygen Sensor Gasboard-7500H Series
Cubic Sensors |
|||||||||
| Parameter | 6500HM | 7500HA-BC | 7500HA-RH | 7500HA | 7500E | 7500K | |||
| Picture |
|
 |
|
|
|||||
| Flow Rate | TBD | 0~2L/min | 0~10L/min | ||||||
| Concentration | 0~100% | 0~100% | 20.5%~95.6% | ||||||
|
TBD | ±0.1L/min | ±0.2L/min | ||||||
| ±2.0%FS | ±1.5%FS | ±3%FS | ±1.5%FS | ±1.8%FS | ±1.5%FS | ||||
|
TBD | 0.01L/min | 0.1L/min | ||||||
| 0.1% | |||||||||
| Temperature Compensation |
|
|
|
|
|
|
|||
| Humidity Compensation |
|
|
|
|
|
|
|||
| Pressure Compensation |
|
|
|
|
|
|
|||
Cubic Fans |
|||
| Parameters/Model | 9733 | 4020 | 12038 |
| Picture |
|
|
|
| Rated Voltage | 12V | 12V | 24V |
| Rated Power | 4.8W | 0.48W | 4.8W |
| Rated Speed | 3200±15%RPM | 5800±15%RPM | 3000±15%RPM |
| Terminal Type | JWT A2501-2P | XH2.54-2P | / |
| Max Airflow | 23.82CFM | 7.42CFM | 104.62CFM |
| Max Pressure | 24.57mmH2O | 5.14mmH2O | 7.65mmH2O |
| Noise Level | 45.32dB(A) | 26.2dB(A) | 46.92dB(A) |
| Dimensions | L94.3*W33*H97.2mm | L40*W20*H40mm | L120*W38*H120mm |
(Non-dispersive Infrared)
(Tunable Diode Laser Absorption Spectroscopy)
(Non-dispersive Infrared)
(Tunable Diode Laser Absorption Spectroscopy)
Founded in 2003, Cubic is a gas sensor company with a comprehensive gas sensor technology platform for measurement from gas composition to gas flow. Cubic has core gas sensor technologies based on NDIR, UVDOAS, NDUV, lasers scattering, Laser Raman and Ultrasonic.In 2008, Cubic had developed the ultrasonic oxygen sensor and flow sensor for oxygen concentrators and ventilators.In 2010, Cubic began to carry out a forward layout in the field of ultrasonic gas meters. Significant breakthroughs in ultrasonic signal processing ensure Cubic to be an industry-leading ultrasonic metering expert. Besides, supply chain integration advantage drives Cubic to be a one-stop supplier for smart gas meters, isolation ball valves, commercial gas regulators, software management systems, etc.In 2022, the newly built industrial park with an area around 48000m² and the production lines for ultrasonic gas meter business will be put into production in Jiashan, which is about 60km driving from the Shanghai Hongqiao International Airport.
Cubic Headquarter
Cubic R&D Center
Cubic Jiashan Factory
Cubic Hungary Factory
In-house Developmentand Manufacturingof Core Gas Sensors and Components
Hardware/Structural Design
Software Development
Mold Development
Prototype Testing/Validation
Optimized Supply ChainInteqratiorYou can contact Cubic by telephone or email, or you can submit an online Request for Quotation Form.
